SE-BLA Multi Fan AC Blower Static Eliminator

220V AC mains-powered long-range ionising blower — up to ~1 metre range, potentiometer fan control, ideal for conveyors, assembly stations and 3D objects

Product Description

The FÖGE SE-BLA is a multi-fan AC blower static eliminator designed for long-range static neutralisation of 3D objects, conveyor lines and assembly stations — applications where a flat antistatic bar mounted close to a surface is impractical or impossible. The unit connects directly to a standard 220V AC mains supply and operates entirely self-contained: it generates its own high-voltage AC ionisation internally, and uses multiple integrated fans to project the resulting ion cloud outward to an effective range of approximately one metre. No external HV power unit, no compressed air supply and no additional infrastructure are required — the SE-BLA needs only a mains outlet and a mounting bracket. The multiple fans produce a high-volume air flow that carries balanced positive and negative ions away from the unit and distributes them broadly across the target area. This wide, high-volume ion delivery is particularly effective on 3D-shaped objects — bottles, boxes, moulded parts, components in bins — where ions must reach around corners, into recesses and onto multiple faces simultaneously, which a directional bar or nozzle system cannot achieve from a fixed position. Fan speed is adjusted continuously with a potentiometer control on the unit, allowing the air volume and ion delivery to be tuned for the working distance and the sensitivity of the application.

Industries

Plastics & Injection Moulding (part collection, conveyor neutralisation)

Electronics & ESD-Sensitive Assembly (operator stations, component handling)

Automotive (plastic component assembly, conveyor lines)

Packaging (component loading, material handling)

Robotics & Industrial Automation (robotic cell static control)

Medical Devices & Pharmaceutical (cleanroom-adjacent assembly)

Consumer Products Manufacturing (assembly lines, quality inspection)

Effective ionisation range approximately 1 metre — true long-range static elimination without compressed air

220V AC mains supply — self-contained unit, no separate HV power unit required

Integrated multiple fans — high air volume distributes ions broadly across 3D objects and wide areas

Fan speed control via potentiometer — stepless adjustment of air volume and ion delivery distance

No compressed air infrastructure required — fans are built in

High-voltage AC ionisation — balanced positive and negative ion output

Stainless steel emitter pins — long service life, shockless design

Excellent performance on 3D objects, complex shapes and parts in bins

Suitable for conveyors, assembly stations and robotic handling zones

Industrial-grade design

Request a Quote

Download Datasheet

Product Description

The FÖGE SE-BLA is a multi-fan AC blower static eliminator designed for long-range static neutralisation of 3D objects, conveyor lines and assembly stations — applications where a flat antistatic bar mounted close to a surface is impractical or impossible. The unit connects directly to a standard 220V AC mains supply and operates entirely self-contained: it generates its own high-voltage AC ionisation internally, and uses multiple integrated fans to project the resulting ion cloud outward to an effective range of approximately one metre. No external HV power unit, no compressed air supply and no additional infrastructure are required — the SE-BLA needs only a mains outlet and a mounting bracket. The multiple fans produce a high-volume air flow that carries balanced positive and negative ions away from the unit and distributes them broadly across the target area. This wide, high-volume ion delivery is particularly effective on 3D-shaped objects — bottles, boxes, moulded parts, components in bins — where ions must reach around corners, into recesses and onto multiple faces simultaneously, which a directional bar or nozzle system cannot achieve from a fixed position. Fan speed is adjusted continuously with a potentiometer control on the unit, allowing the air volume and ion delivery to be tuned for the working distance and the sensitivity of the application.

Industries

Plastics & Injection Moulding (part collection, conveyor neutralisation)

Electronics & ESD-Sensitive Assembly (operator stations, component handling)

Automotive (plastic component assembly, conveyor lines)

Packaging (component loading, material handling)

Robotics & Industrial Automation (robotic cell static control)

Medical Devices & Pharmaceutical (cleanroom-adjacent assembly)

Consumer Products Manufacturing (assembly lines, quality inspection)

Effective ionisation range approximately 1 metre — true long-range static elimination without compressed air

220V AC mains supply — self-contained unit, no separate HV power unit required

Integrated multiple fans — high air volume distributes ions broadly across 3D objects and wide areas

Fan speed control via potentiometer — stepless adjustment of air volume and ion delivery distance

No compressed air infrastructure required — fans are built in

High-voltage AC ionisation — balanced positive and negative ion output

Stainless steel emitter pins — long service life, shockless design

Excellent performance on 3D objects, complex shapes and parts in bins

Suitable for conveyors, assembly stations and robotic handling zones

Industrial-grade design

Request a Quote

Download Datasheet

How It Works

The SE-BLA connects to a standard 220V AC mains supply. Internally, the unit contains a high-voltage AC ionisation circuit that applies AC high voltage to a row of stainless steel emitter pins. The elevated voltage causes intense ionisation of the air immediately around the pins, generating balanced positive and negative ions — identical in principle to the SE-ACB bars, but without requiring an external SE-PAC power unit since the HV generation is built into the SE-BLA itself. The multiple integrated fans draw in ambient air and push it through the ionisation zone at the emitter pins, picking up the freshly generated ions and projecting them outward from the unit toward the target area. The fans produce a broad, high-volume air stream — not a focused nozzle jet — which distributes ions across a wide area at distances up to approximately one metre. The potentiometer on the unit controls the fans' speed: at maximum speed, maximum air volume is produced and ions are projected furthest; at reduced speed, the air is gentler and more suitable for lightweight or sensitive applications. The alternating AC polarity ensures that both positive and negative ions are continuously produced in balance, neutralising both polarities of static charge on the target.

Request a Quote

Download Datasheet

Advantages & Benefits

01

~1 metre range — no bars, no air lines

The SE-BLA reaches static charges at up to approximately 1 metre without any compressed air infrastructure, without HV cabling and without mounting a bar close to the product. One unit covers a wide area.

02

Self-contained — plug and go

220V AC mains input is all that is required. No SE-PAC power unit to mount, no compressed air to connect, no M8/M12 DC cabling — the SE-BLA is as simple to install as any mains appliance.

03

Outstanding performance on 3D objects

The high air volume from multiple fans wraps ions around all faces of 3D objects simultaneously — bottles, boxes, moulded parts, components in bins — in ways that a flat bar or directional nozzle cannot replicate.

04

Tunable to the application

The potentiometer allows continuous adjustment of fan speed — turn it up for maximum range and air volume, turn it down for sensitive applications where too much air movement would disturb lightweight parts.

05

Wide-area coverage

Unlike a bar that covers a single line, the SE-BLA distributes ions in a broad cloud — covering a wide conveyor width, an entire assembly station, or a robotic cell from a single overhead position.

06

No HV power unit cost

Because the HV generation is built into the SE-BLA, there is no need to purchase and mount a separate SE-PAC power unit — reducing total system cost.

Key Features

Effective ionisation range approximately 1 metre — true long-range static elimination without compressed air

220V AC mains supply — self-contained unit, no separate HV power unit required

Integrated multiple fans — high air volume distributes ions broadly across 3D objects and wide areas

Fan speed control via potentiometer — stepless adjustment of air volume and ion delivery distance

No compressed air infrastructure required — fans are built in

High-voltage AC ionisation — balanced positive and negative ion output

Stainless steel emitter pins — long service life, shockless design

Excellent performance on 3D objects, complex shapes and parts in bins

Suitable for conveyors, assembly stations and robotic handling zones

Industrial-grade design

Request a Quote

Download Datasheet

Which Blower to Choose — SE-BLA, SE-BLC or SE-BLL

FÖGE offers three ionising blower types. Use the table to select the right product for your installation:

Comparison	SE-BLA (this product)	SE-BLC-F-75-C	SE-BLL
Technology	AC ionisation	Pulsed DC ionisation	Pulsed DC ionisation
Power Supply	220V AC mains — self-contained	24 V DC (SE-PSU-24-C-M12)	24 V DC (SE-PSU-24-C-M12)
HV Unit Required	No — built-in	No — built-in	No — built-in
Air Source	Integrated multiple fans	Integrated single fan	Integrated fans — laminar flow
Fan Control	Potentiometer — stepless	Front panel buttons	Front panel buttons
Effective Range.	~1000 mm	~500 mm	Up to 1000 mm
Best For	Conveyor belts, assembly stations, spaced-out 3D parts — wide-area coverage	Compact installations, robotic arms, ESD stations	Wide-web and strip-format applications — uniform laminar coverage

Applications

Application	Where it helps
Conveyor Lines — 3D Part Neutralisation	Mount above a conveyor belt to deliver ions to passing 3D objects—bottles, cardboard boxes, injection-molded parts —at a distance of approximately 1 meter.
Assembly Stations	Continuous static elimination at manual assembly stations where operators handle plastic components. The wide ion cloud neutralizes the components as well as the operators’ hands and tools.
Robotic Handling Cells	Install in fixed positions within robotic cells to stabilize plastic components during gripping, placement, or transfer.
Injection Moulded Part Collection	Position above or next to sub-collectors and conveyor belt outlets on injection molding machines —to neutralize freshly molded parts as they are collected.
Quality Inspection Stations	Install over test stations where clean, static-free surfaces are required for visual or automated optical inspection.
Packaging Lines — Component Loading	Neutralise components and packaging materials at loading and assembly stations on packaging lines — preventing static from attracting dust to components before they are sealed in the final package.

Installation Notes

Mount the SE-BLA unit above or beside the target zone — typically 500–1000 mm from the target objects depending on the required ionisation intensity and the fan speed setting. Use a sturdy bracket rated for the unit's weight. Connect the unit to a standard 220V AC mains supply via the supplied cable. Ensure the mains circuit is protected by an appropriate fuse or circuit breaker. Set the potentiometer to the minimum (lowest fan speed) before switching on. Switch the unit on, then gradually increase the fan speed until the required ion delivery is achieved at the working distance. Use an SE-SFM-030 fieldmeter to verify static levels at the target surface. For conveyor applications, position the unit so the ion air stream is directed at the product at the point where neutralisation is most needed — typically just before the product reaches a critical process station such as inspection, assembly or packaging. For assembly station applications, mount the unit above or to the side of the workstation so the ion cloud covers the full working area. The broad distribution of the multi-fan design typically covers a workstation without precise aiming.

Request a Quote

Download Datasheet

Technical Specifications

Product code	Color	Dimensions (mm)	Power Consumption	Wavelength	Datasheet
VL-BAL-25-400-R-24-C30	Red	25 x 400	–	621nm	Download
VL-BAL-25-400-W-24-C30	White	25 x 400	–	6500K	Download
VL-BAL-25-400-G-24-C30	Green	25 x 400	–	528nm	Download
VL-BAL-25-400-B-24-C30	Blue	25 x 400	–	470nm	Download
VL-BAL-25-400-I-24-C30	Infrared	25 x 400	–	940nm	Download
VL-BAL-25-500-R-24-C30	Red	25 x 400	–	621nm	Download

Parameter

Specification

Product code

SE-BLA * (Please contact FÖGE for the complete order code)
Ionisation type

Alternating current – high voltage, surge-free
Grid connection

220 V AC · 50 Hz (self-contained – no separate high-voltage power supply required)
Grid connection

Multiple integrated fans – no compressed air infrastructure required
Fan speed control

Potentiometer – stepless adjustment of fan speed and air volume
Effective ionization range

Up to ~1000mm (approximately 1 meter - depending on fan speed) *
Best For

3D objects, conveyor belts, assembly stations, robot-assisted handling – ion transport over long distances and in high volumes
Emitter Pin Material

Stainless steel – long service life, impact-resistant design
Polarity

Alternating current – balanced positive and negative ion output
Housing

Industrial quality
EMC compliance

2014/30/EU — EMC Directive *
Electrical safety

2014/35/EU — Low Voltage Directive *

* Parameters marked * are based on product family context and user specification. Confirm exact ordering code, range specification and full compliance details from the official SE-BLA datasheet before publishing.

Do you have any questions about this product?

Frequently Asked Questions

No. The SE-BLA is entirely self-contained. The HV AC ionisation circuit is built into the unit. Connect it to a standard 220V AC mains outlet — no SE-PAC, no 24V DC supply and no compressed air are needed.

No. The SE-BLA uses its own integrated fans to move air — no compressed air supply is required at the installation point. This makes it easier to install than compressed-air-based systems in locations where air lines are not available.

The SE-BLA is a 220V AC mains unit with multiple fans, potentiometer control and approximately 1 metre range — designed for wide-area, long-range coverage of 3D objects and open spaces such as conveyors and assembly stations. The SE-BLC is a compact 24V DC pulsed DC blower with a single fan, front panel button control and approximately 500 mm range — designed for more compact, close-to-medium range applications such as robotic arms and ESD workstations.

The SE-BLA produces a broad, high-volume ion cloud from multiple fans — ideal for 3D objects and wide open areas at up to ~1 metre. The SE-BLL produces a wide, uniform laminar sheet of ionised air from a bar-format unit — ideal for wide web applications (film, paper, foil) where even ion distribution across a full-width flat surface is required.

Start at low fan speed and increase gradually while monitoring static levels at the target using an SE-SFM-030 fieldmeter. The correct setting is the lowest fan speed that achieves the required static reduction at the working distance — this minimises air disturbance to lightweight parts and reduces noise.
